4axis Rotary Tilting Tables

Specifications

ITEM		UNIT		RDC170R
Table diameter		mm		170
Center height		mm		135
Center bore	Front spindle hole	mm		55H7
Center bore	Through hole	mm		36H7
T slot width		mm		12H7
Guide block width		mm(h7)		14h7
Servo Motor		FANUC	α	αiF4	□130
		FANUC	β	βiS8	□130
		Mitsubushi		HF-104T	□130
Motor interface		Siemens		1FK7060	□126
Gear ratio		--		1/45 (1/36)
Table max.		r.p.m.		83 (100)
Degree mini.		Degree		0.001
Accuracy		Second		20
Forward & Reverse repet.accuracy		Second		5
Allowable cutting torque		【kgf-m】		【37】
Allowable cutting torque		N-m		362
Clamp system		Pneumatic/ Hydraulic		Pneumatic
Clamp output at brake		kg-cm²		6
Clamp output torque at brake		【kgf-m】		【20】
Clamp output torque at brake		N-m		196
Allowable work weight	(Radial) Straight	kg		80
	(Tailstock applied)	kg		160
	(Axial) Flat	kg		160
Allowable load (table clamped)		F	Kgf	1850
		F	N	18130
		FxL	Kgf-m	【20】
		FxL	N-m	196
		FxL	Kgf-m	105
		FxL	N-m	1029
Weight		kg		60
Allowable inertia force		kg-m²		1.25
