4axis Rotary Tilting Tables
RD Series (R/L)
RD270L
Specifications
| ITEM | UNIT | RD270L | |||
|---|---|---|---|---|---|
| Table diameter | mm | 270 | |||
| Center height | mm | 185 | |||
| Center bore | Front spindle hole | mm | 90H7 | ||
| Through hole | mm | 60H7 | |||
| T slot width | mm | 12H7 | |||
| Guide block width | mm(h7) | 18h7 | |||
| Servo Motor | FANUC | α | αiF8 | □130 | |
| β | βiS8 | □130 | |||
| Mitsubushi | HF-154T | □130 | |||
| Motor interface | Siemens | 1FK7063 | □126 | ||
| Gear ratio | -- | 1/60 | |||
| Table max. | r.p.m. | 50 | |||
| Degree mini. | Degree | 0.001 | |||
| Accuracy | Second | 13 | |||
| Forward & Reverse repet.accuracy | Second | 4 | |||
| Allowable cutting torque | 【kgf-m】 | 【74】 | |||
| N-m | 725 | ||||
| Clamp system | Pneumatic/ Hydraulic | Pneumatic/ Hydraulic | |||
| Clamp output at brake | kg-cm² | 6/25 | |||
| Clamp output torque at brake | 【kgf-m】 | 【40/121】 | |||
| N-m | 392/1190 | ||||
| Allowable work weight | (Radial) Straight | kg | 255 | ||
| (Tailstock applied) | kg | 500 | |||
| (Axial) Flat | kg | 500 | |||
| Allowable load (table clamped) |
F | Kgf | 4300 | ||
| N | 42140 | ||||
| FxL | Kgf-m | 【40/93】 | |||
| N-m | 392/911 | ||||
| FxL | Kgf-m | 490 | |||
| N-m | 4802 | ||||
| Weight | kg | 126 | |||
| Allowable inertia force | kg-m² | 7.6 | |||
Size Drawings
RD270L
Laser Accuracy Inspection Form
