ATC Systems

Vertical Tool Change -Magazine on the right

BT50 Series

A502 - Right Mag.

Outline Drawing

renishaw-acu250-r-asis-corrected

ContRoller-Types

Movement Timing Illustration



size-drawings-acu250-en-01

Angle for cutter change can be defined per customer's need (60°~ 90°)

top-view-drawing-acu250-02

We can customize strokes according to different types of tool holders

A502 Instant Loading Diagram

Tool Change Arm T-to-T Distance/ Tool Arm Weight Reference
Tool Weight
Bilateral Loading of Tools
Motor Frequency Belts Compatible with
1.5HP
ATC Time Interval
For Cutter
10Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
15Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
20Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
25Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
30Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
Tool Weight
Bilateral Loading of Tools
Motor Frequency Belts Compatible with
1.5HP
ATC Time Interval
For Cutter
10Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
15Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
20Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
25Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
30Kgx2 50Hz 41:48 2.91 sec
60Hz 38:50 2.75 sec
Tool Weight
Bilateral Loading of Tools
Motor Frequency Belts Compatible with
1.5HP
ATC Time Interval
For Cutter
10Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
15Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
20Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
25Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
30Kgx2 50Hz 41:48 2.91 sec
60Hz 38:50 2.75 sec
Tool Weight
Bilateral Loading of Tools
Motor Frequency Belts Compatible with
1.5HP
ATC Time Interval
For Cutter
10Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
15Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
20Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
25Kgx2 50Hz 41:48 2.91 sec
60Hz 38:50 2.75 sec
30Kgx2 50Hz 41:48 2.91 sec
60Hz 38:50 2.75 sec
Tool Weight
Bilateral Loading of Tools
Motor Frequency Belts Compatible with
1.5HP
ATC Time Interval
For Cutter
10Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
15Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
20Kgx2 50Hz 41:48 2.91 sec
60Hz 38:50 2.75 sec
25Kgx2 50Hz 41:48 2.91 sec
60Hz 35:50 2.99 sec
30Kgx2 50Hz 38:50 3.27 sec
60Hz 35:53 3.17 sec
Tool Weight
Bilateral Loading of Tools
Motor Frequency Belts Compatible with
1.5HP
ATC Time Interval
For Cutter
10Kgx2 50Hz 41:48 2.91 sec
60Hz 41:48 2.45 sec
15Kgx2 50Hz 41:48 2.91 sec
60Hz 38:50 2.75 sec
20Kgx2 50Hz 38:50 3.27 sec
60Hz 35:50 2.99 sec
25Kgx2 50Hz 38:50 3.27 sec
60Hz 30:53 3.7 sec
30Kgx2 50Hz 35:50 3.55 sec
60Hz 30:53 3.7 sec
Tool Weight
Bilateral Loading of Tools
Motor Frequency Belts Compatible with
1.5HP
ATC Time Interval
For Cutter
10Kgx2 50Hz 41:48 2.91 sec
60Hz 38:50 2.75 sec
15Kgx2 50Hz 41:48 2.91 sec
60Hz 35:50 2.99 sec
20Kgx2 50Hz 38:53 3.27 sec
60Hz 35:53 3.17 sec
25Kgx2 50Hz 35:50 3.55 sec
60Hz 30:53 3.7 sec
30Kgx2 50Hz 35:53 3.76 sec
60Hz 35:67 4.01 sec
Tool Change Arm T-to-T Distance/ Tool Arm Weight Reference
Tool Weight
Bilateral Loading of Tools
Motor Frequency Belts Compatible with
1.5HP
ATC Time Interval
For Cutter
10Kgx2 50Hz 41:48 2.91 sec
60Hz 38:50 2.75 sec
15Kgx2 50Hz 38:50 3.27 sec
60Hz 35:53 3.17 sec
20Kgx2 50Hz 35:50 3.55 sec
60Hz 35:53 3.7 sec
25Kgx2 50Hz 35:53 3.76 sec
60Hz 30:53 3.7 sec
30Kgx2 50Hz 35:53 4.39 sec
60Hz 30:67 4.01 sec
Tool Weight
Bilateral Loading of Tools
Motor Frequency Belts Compatible with
1.5HP
ATC Time Interval
For Cutter
10Kgx2 50Hz 41:48 2.91 sec
60Hz 35:50 2.99 sec
15Kgx2 50Hz 38:50 3.27 sec
60Hz 30:53 3.7 sec
20Kgx2 50Hz 35:53 3.76 sec
60Hz 30:53 3.7 sec
25Kgx2 50Hz 30:53 4.39 sec
60Hz 35:67 4.01 sec
30Kgx2 50Hz 30:53 4.39 sec
Tool Weight
Bilateral Loading of Tools
Motor Frequency Belts Compatible with
1.5HP
ATC Time Interval
For Cutter
10Kgx2 50Hz 38:50 3.27 sec
60Hz 35:50 2.99 sec
15Kgx2 50Hz 35:53 3.76 sec
60Hz 30:53 3.7 sec
20Kgx2 50Hz 30:53 4.39 sec
60Hz 35:67 4.01 sec
25Kgx2 50Hz 30:53 4.39 sec
